Wattages:
60W
|
|
Efficacy:
170lm/W
|
|
MacAdam Ellipse (SDCM):
SDCM: <6
|
|
IP Rating:
IP66
|
|
IK Rating:
IK10
|
|
Voltage:
AC120-277V, 50/60Hz
|
|
Light Source & Brand:
LED: SMD 5050
|
|
Driver:
Driver: SOSEN
|
|
Size - Length:
Length: 568mmL
|
|
Size - Width:
Width: 206mmW
|
|
Size - Height:
Height: 104mmH
|
|
Spigot - Diameter:
Spigot: 64mm Ø
|
|
Weight:
Weight: 3.5kg
|
|
Tilt:
Tilt: ±15°
|
|
Beam Angle:
Beam Angle: Type II-M - 155° x 70°
|
|
Material of Housing:
Housing Material: Aluminum Alloy
|
|
Material of Optics:
Optics Material: Polycarbonate Lens
|
|
Corrosion Resistance:
Corrosion Resistance: C5
|
|
Operating Temperature:
Operating Temperature: -40°C to+50°C
|
|
Lifetime:
Reported L80 @ 85° >102,000 Hrs - As outlined within IESNA Standards, Projected Lifetime can be up to 6 x the reported lifetimes
|
|
IES Data:
AES-03-PL01-G10 Type II-M Axial
|
